Specifications
Rotational Speed 5,400 RPM (nominal)
Buffer Size 8 MB
Average Latency 5.50 ms (nominal)
Read Seek Time 12.0 ms; Track-To-Track Seek Time 2.0 ms (average)
Transfer Rates: Buffer To Host (Serial ATA) 3 Gb/s (Max)
Physical Specifications
Formatted Capacity 500,107 MB
Capacity 500 GB
Interface SATA 3 Gb/s
User Sectors Per Drive 976,773,168
Physical Dimensions
Height 9.5 mm ±0.20 mm
Length 100.2 ±0.25 mm
Width 69.85 ±0.25 mm
Weight 0.117 kg
Environmental Specifications
Acoustics
Idle Mode 24 dBA (average)
Seek Mode 0 26 dBA (average)
Vibration
Operating 0.00459 g²/Hz (10 to 500 Hz)
Non-operating 0.05102 g²/Hz (10 to 500 Hz)
Electrical Specifications
Current Requirements
5 VDC
Read/Write 500 mA
Idle 400 mA
Standby 50 mA
Sleep 20 mA
Power Dissipation
Read/Write 2.50 Watts
Idle 0.85 Watts
Standby 0.25 Watts
Sleep 0.10 Watts
| |
| |
|
|
|
|
| |
|
