GENERAL
General type Monochrome multifunctionals for A4/A3 format
Technology KYOCERA ECOSYS Laser
Engine speed Up to 25/12 pages A4/A3 per minute (print/copy)
Warm-up time 20 seconds or less from power on
Time to first print Approx. 8 seconds or less
Time to first copy Approx. 9.2 seconds or less (DP), 7.8 seconds or less (Platen Cover)
Dimensions (W x D x H) 590 x 590 x 694 mm
Weight Approx. 52.2 kg including toner container
Power consumption Sleep-mode: 1 W, Stand-by: 119 W, Copying/Printing: 553 W
Power source AC 220 ~ 240 V, 50/60 Hz
Noise (ISO 7779) Copying/Printing: 45.5 dB(A), Stand-by: 25.4 dB(A)
Safety standards TÜV/GS, CE - This product is manufactured according to ISO 9001 quality standard and ISO 14001 environmental standard.
General memory 512 MB, max. 1,536 MB
PAPER HANDLING
Input capacity 100-sheet multi-purpose tray, 45–256 g/m² (52–163 g/m² for larger than A4/Letter size), A3, A4, A5, A6, B5, Letter, Legal, Folio, envelopes, Custom (98 x 148 to 297 x 432 mm) 500-sheet universal paper cassette, 60–163 g/m², A3, A4, A5, B5, Letter, Legal, Folio
Max. input capacity with options 1,600 sheets
Duplex unit Duplex as standard supports 60–163 g/m²
Max. output capacity Max. 300 sheets: 250 sheets face-down (main tray), plus 50 sheets (job separator tray)
Document processor Reversing document processor: 50-sheet, Simplex scan 45–160 g/m², Duplex scan 50–120 g/m², A3, A4, A5, B5, Letter, Legal, Custom (140x182 to 297x432mm)
General paper handling All paper capacities quoted are based on a paper thickness of max. 0.11 mm. Please use paper recommended by KYOCERA under normal environmental conditions.
PRINT
Processor PowerPC 464 - 800 MHz
Controller language PRESCRIBE IIe
Emulations PCL 6 (5e/XL), KPDL3 (Postscript 3 compatible), PDF Direct print, XPS Direct print
Fonts 93 outline fonts (PCL 6, KPDL3) + 8 (Windows Vista), 45 types of one-dimensional barcodes, 1 type of twodimensional barcode (PDF417)
Integrated Accounting 100 department codes
Features encrypted PDF Direct Print, IPP printing, e-mail printing, WSD print, secure printing via SSL, IPsec, SNMPv3, Private Print (requiers memory expansion)
Standard Interfaces USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10/100/1000Base-TX, slot for optional print server, slot for optional CompactFlash®-Card
Resolution 600 x 600 dpi
Applicable OS All current Windows operating systems, MAC OS X Version 10.4 or higher, Unix, Linux as well as other operating systems on request
COPY
Copy resolution 600 x 600 dpi
Max. original size A3/Ledger
Digital copy features Scan-once-copy-many, electronic sort, 2in1, 4in1, job reserve, priority print, program, auto duplex copy, split copy, continuous scan, auto cassette change (PF-470 or PF-471 is required), copy density control, Prevent Bleed-Through
Exposure modes Auto, manual: 7 steps
Preset magnification ratios 5 Reductions/5 Enlargements
Zoom range 25 - 400 % in 1% steps
Continuous copy 1 - 999
Image adjustments Text, Photo, Text + Photo, Graphic/Map, Copy/Printout
SCAN
Interfaces Fast Ethernet 10/100/1000Base-TX, USB Host 2.0
File type PDF, PDF/A, JPG, TIFF, XPS
Scan features Integrated address book, encrypted data transfer, multi send (email, fax, SMB/FTP folder, print) at once
Original recognition Text, photo, text + photo, OCR
Max. scan size A3/Ledger
Scan functionalities Scan-to-email, Scan-to-FTP, Scan-to-SMB, Scan to USB Host, Network TWAIN, WIA, WSD scan
Scan resolution 200 dpi, 300 dpi, 400 dpi, 600 dpi (256 greyscales per colour)
Scan speed 40 ipm (300 dpi, A4, b/w), 20 ipm (300 dpi, A4, colour)
FAX
Compatibility ITU-T Super G3
Modem speed Max. 33.6 kbps
Scanning speed 2.0 seconds (Quick Scanning, Bitmap)
Transmission speed 3 seconds or less
Scanning density Normal: 8 dot/mm x 3.85 line/mm, Fine: 8 dot/mm x 7.7 line/mm, Superfine: 8 dot/mm x 15.4 line/mm, Ultrafine: 16 dot/mm x 15.4 line/mm, Halftone: 256 gray scales
Max. original size A3/Ledger
Compression method JBIG, MMR, MR, MH
Fax features Network fax, duplex transmission and reception, encrypted transmission and reception, polling transmission and reception, broadcast
INTERFACES
Standard interface USB 2.0 (Hi-Speed), USB Host 2.0, Fast Ethernet 10/100/1000Base-TX, slot for optional print server, slot for optional CompactFlash®-Card
WARRANTY
Warranty 1-year warranty as standard. KYOCERA guarantees the drum and developer for 3 years or 300,000 pages (whichever occurs sooner), provided each device is used and cleaned in accordance with the service instructions.
| |
