Product Description
Device Interfaces
RJ-11 ADSL port
4 RJ-45 10/100BASE-TX Ethernet ports with auto MDI/MDIX
Built-in 802.11n wireless LAN
Factory reset button
WPS button
Wireless on/off switch
USB 2.0 port
Wireless LAN
2 x 5dBi non-removable antennas
802.11b/g/n standards
Wireless speed: up to 54Mbps (802.11G), 300Mbps (802.11n)3
Frequency: 2.4 GHz to 2.484G Hz
Dual 2x2 built-in MIMO antennas
64/128 bits WEP data encryption
WPA/WPA2 (Wi-Fi Protected Access)
Multiple SSID
802.11e Wireless QoS (WMM/WME)
MAC address-based access control
ADSL Standards
ADSL standards: Multi-mode, ANSI T1.413 Issue 2, ITU G.992.1 (G.dmt) Annex A, ITU G.992.2 (G.lite) Annex A, ITU G.994.1 (G.hs)
ADSL2 standards: ITU G.992.3 (G.dmt. bis) Annex A/L/M, ITU G.992.4 (G.lite. bis) Annex A
ADSL2+ standards: ITU G.992.5 Annex A/L/M
Firewall
Built-in NAT firewall
Stateful Packet Inspection (SPI)
DoS attacks prevention
Packet filtering (IP/ICMP/TCP/UDP)
Intrusion Detection System (IDS)
DMZ
ATM & PPP Protocols
ATM Forum UNI3.1/4.0 PVC (up to 16PVCs)
ATM Adaptation Layer Type 5 (AAL5)
Bridged or Routed Ethernet encapsulation
ATM QoS (Traffic Shaping)
VC and LLC based multiplexing
PPP over Ethernet (PPPoE)
PPP over ATM (RFC 2364)
ITU-T I.610 OAM F4/F5
Router Features
NAT (maximum 4096 NAT sessions)
DHCP server/client/relay
Static Routing, RIP v.1, v.2
Universal Plug and Play (UPnP)
Dynamic Domain Name System (DDNS)
Virtual Server
SNTP, DNS proxy and IGMP proxy
SharePort™ Plus for sharing of USB 2.0 devices
Virtual Private Network (VPN)
Multiple PPTP/IPSec/L2TP passthrough
Device Configuration / Management
Installation Wizard
Web-based GUI for configuration, firmware upgrade
Code lock to prevent improper firmware upgrade
Telnet with SSH support
Syslog monitoring
SNMP v1, v2c support with built-in MIB-II (RFC 1213)
TR-069 Client
WPS
Quality of Service (QoS)
LAN to WAN traffic prioritization/ classification
802.1p (0 to 7) traffic prioritization
Traffic Shaping
Security
IGMP Snooping with 32 Multicast groups
PVC/VLAN port mapping (bridge mode)
Parental Control (URL blocking)
